Aviary Zoo Mesh Stainless Steel Hand-Woven Ferruled Cable Wire Rope Mesh

Aviary Zoo Mesh Stainless Steel Hand-Woven Ferruled Cable Wire Rope Mesh
Aviary Zoo Mesh Stainless Steel Hand-Woven Ferruled Cable Wire Rope Mesh
Aviary Zoo Mesh Stainless Steel Hand-Woven Ferruled Cable Wire Rope Mesh Aviary Zoo Mesh Stainless Steel Hand-Woven Ferruled Cable Wire Rope Mesh
Basisinformatie
Plaats van herkomst: Hebei
Merknaam: Yuntong
Certificering: CE , SGS
Modelnummer: YT-FF
Min. bestelaantal: 10 m²
Verpakking Details: Pakketfilm voor elk stuk, verschillende stukken verpakt in 1 doos
Levertijd: 5-8 werkdagen
Betalingscondities: T/T, Western Union, PayPal
Levering vermogen: 300 m²/week
Contact nu
Productnaam: Roestvrijstalen handgeweven geferruleerde kabeldraad touwgaas Draadkabel: 1,2 mm tot 4,0 mm
Touwconstructies: 7 x 7, 7 x 19, 1 x 19 Afgerond: Ultrasone bad / zwart oxide
Mesh -oriëntatie: Horizontaal, verticaal Materiaal: Roestvrij staal 304, 316, 316L
Gaasvorm: Rhombus, diamant Sollicitatie: Dierenhok, aaphok, tijgerhok, enz.
Markeren:

stainless steel zoo wire mesh

,

hand-woven ferruled cable mesh

,

aviary stainless steel rope mesh

Stainless Steel Hand-Woven Ferruled Cable Wire Rope Mesh

The Zoo Wire Mesh is manufactured in the standard diameters 1.0 mm, 1.5 mm, 1.6mm, 2.0 mm, 3.0 mm and 3.2mm. Mesh width of 25 to 200 mm (or bigger) are possible depending on cable diameter.
Rope Mesh is manufactured from high-grade stainless steel cables of material class 1.4401, AISI316.
Mesh connections (ferrules) are available in highly aesthetic stainless steel for premium applications or where resistance to corrosion is a driving consideration.
Finished diamond mesh style when it is stretched at 60 degree angle ;

Zoo Wire Mesh Specifications Sheet :

Hole Size

(Opening)

1.2MM(3/64)

(7 x 7 )

1.6MM(1/16)

(7 x 7 )

2.0MM(5/64)

(7 x 7 )

2.4MM(3/32)

(7 x 7 )

3.2MM(1/8)

(7 x 19 )

20 x 35mmYT-1235
25 x 42mmYT-1225YT-1625
30 x 52mmYT-1230YT-1630YT-2030
35 x 60mmYT-1235YT-1635YT-2035
38 x 66mmYT-1238YT-1638YT-2038YT-2438
40 x 69mmYT-1240YT-1640YT-2040YT-2440YT-3040
50 x 86mmYT-1250YT-1650YT-2050YT-2450YT-3050
60 x 104mmYT-1260YT-1660YT-2060YT-2460YT-3060
70 x 120mmYT-1270YT-1670YT-2070YT-2470YT-3070
76 x 131mmYT-1276YT-1676YT-2076YT-2476YT-3076
80 x 138mmYT-1280YT-1680YT-2080YT-2480YT-3080
90 x 154mmYT-1290YT-1690YT-2090YT-2490YT-3090
100 x 173mmYT-12100YT-16100YT-20100YT-24100YT-30100
120 x 206mmYT-12120YT-16120YT-20120YT-24120YT-30120


1. Material of Stainless Steel Zoo Wire  Mesh : Stainless steel 304,304L,316,306L etc.

SS304(%) C:≤0.07, Si :≤1.0, Mn :≤2.0, Cr :17.0-19.0, Ni :8.0-11.0, S :≤0.03, P :≤0.035
SS316(%) C:≤0.08, Si:≤1.00, Mn:≤2.00, P≤:0.035, S:≤0.03, Ni:10.0-14.0, Cr:16.0-18.5
SS316L(%)C:≤0.03, Si:≤1.00, Mn:≤2.00, P:≤0.045, S:≤0.030, Cr:16.0～18.0, Ni:12.0～15.0


Recommended Monkey Enclosure Zoo Wire Mesh:


MaterialCable DiameterHole SizeNormal Break
SS304/316/316L3/32" (2.4MM)2.5" x 2.5"920 LBS
SS304/316/316L3/32" (2.4MM)2" x 2"920 LBS
SS304/316/316L5/64" (2.0MM)2.5" x 2.5"676 LBS
SS304/316/316L5/64" (2.0MM)2" x 2"676 LBS
SS304/316/316L1/8" (3.2MM)2" x 2"1600 LBS
SS304/316/316L1/8" (3.2MM)3" x 3"1600 LBS


Stainless steel zoo wire is light, robust, and transparent. High-quality stainless steel cables and pressed ferrules are used for the production of the mesh and connected to a load-bearing and flexible structure. The curvature in the opposite direction of the stainless steel cables creates the exceptionally robust characteristics of the mesh can even stand up to heavy loads.

Aviary Zoo Mesh Stainless Steel Hand-Woven Ferruled Cable Wire Rope Mesh 0Aviary Zoo Mesh Stainless Steel Hand-Woven Ferruled Cable Wire Rope Mesh 1Aviary Zoo Mesh Stainless Steel Hand-Woven Ferruled Cable Wire Rope Mesh 2
